Air Compressors


The Gardner Denver LRS-Series compressor designs feature high-quality, sound-insulating enclosure panels and a low-noise, thermostatically- controlled, motor-driven fan. These components reduce the noise to whisper-quiet levels and eliminate the need for a separate compressor room, saving money on installation costs.

  •  Direct drive, oil flooded, single stage rotary screw air compressor
  •  AEON 9000SP lubricant
  •  Air-cooled standard
  •  Air supply piping includes hard pipe design with Viton Victaulic couplings
  •  Eaton inverter drive
  •  CRN and ASME rated aftercooler
  •  Electrical components UL listed for the US and Canada, including C-UL-US listed open control panel
  •  EMC filter and DC bus choke
  •  Governor™ microprocessor controller
  •  Integrated spin-on oil filter
  •  Integrated thermostatic thermal mixing valve
  •  Type 1 electrical enclosure
  •  Moisture separator (shipped loose)
  •  Multi-compressor sequencing
  •  Optional line reactor (shipped loose)
  •  Optional water cooling
  •  Quiet enclosure
  •  Built-in data logging
  •  Second pressure band control for lead/lag operation
  •  TEFC main motor
  •  Two-stage air filter and air/oil separation system

Machine Configuration

Horsepower: 125

Pressure: 125

Cubic Feet per Minute: 583

Mounted Tank: NO

Mounted Dryer:

Lubricant: AEON 9000SP lubricant

Dimensions & Weights

Length / Width / Height: 92 X 54 X 80.3

Electical Power Service Requirements

460v / 3phase
