1000HP MOBILE BOILER SETUP – 150PSIG MAWP STEAM

EQUIPMENT #B134

1000HP MOBILE BOILER SETUP – 150PSIG MAWP STEAM

EQUIPMENT #B134

Johnston PFTA-1000-4HG-150 boiler, 150 psig design, 4-Pass Wetback, skid mounted packaged fire tube boiler, manufactured in 1991, with 5000 sq. ft. heating surface. Updated October 2020 with new Webster Low Nox Burner. This stand-alone boiler includes the following components:

  • Low-Water Cutoff

  • Water Column and sight glass

  • Autoflame Controls

  • Safety Valves

  • Blowdown valves

  • Steam Non-Return valve (loose)

  • Stack (loose)

  • Stack

  • Weatherproofed (not freeze proofed)

Download PDF

Boiler Specifications

FUEL CONSUMPTION

NATURAL GAS

40.331 MBH

#2 OIL

N/A

CONNECTION SIZES

HW SUPPLY AND RETURN

10" 150#

NATURAL GAS

#2 OIL SUPPLY & RETURN

N/A

FEEDWATER

2"

BOTTOM BLOWDOWN

2"

CONTINUOUS BLOWDOWN

2"

CHEMICAL FEED

NOT INCLUDED

FUEL OUTLET DIAMETER

26"

ELECTRICAL POWER SERVICE REQUIREMENTS

480V/3PH 60Hz 120A

ELECTRICAL POWER SERVICE REQUIREMENTS

LENGTH/WIDTH/HEIGHT

30' - 6" / 11' - 1" / 11' - 11'

SHIPPING WEIGHT

79,000 LBS

OPERATING WEIGHT

125,000 LBS
