Limpsfield burners are known for their exceptional efficiency, reliability, and adaptability across various industrial applications. Established in 1995, Limpsfield Combustion has been at the forefront of burner technology, delivering solutions that meet the diverse needs of industries worldwide.
Key Features of Limpsfield Combustion Burners:
-
High Turndown Ratios: These burners offer turndown ratios typically between 4:1 and 10:1.
- Fuel Flexibility: These burners are capable of firing a wide range of fuels. This includes natural gas, diesel, #2 oil, heavy fuel oil, waste oils, animal fats, fish oils, and biogases.
- Guaranteed Efficiency: Limpsfield guarantees that their burners will operate at 3% O₂ and less than 10 ppm of CO throughout the complete firing range.(from low to high fire)
- Robust Construction: Designed and manufactured in the UK, featuring stainless steel diffusers and blast tube cones, large rear flame viewing ports. The construction also allows easy access to internal components for maintenance.
Low NOx Emissions
Limpsfield burners meet stringent U.S. federal codes for low NOx emissions. They achieve sub-30 ppm NO emissions at 3% O₂ through flue gas recirculation and superior flame retention. This makes Limpsfield burners an environmentally friendly choice for facilities focused on reducing carbon intensity scores.
Advanced Control Systems:
Limpsfield burners are equipped with Autoflame burner control systems as standard. These controls are user-friendly, featuring touch screen LCD displays, allowing for precise management of the combustion process.
Quality Assurance:
Committed to delivering high-quality products, Limpsfield operates under an ISO9001:2015 certified Quality Management System. Their burners are UL and CE approved, ensuring compliance with international safety and performance standards.
Advanced Oil and Gas Control Systems
- Oil Control: Limpsfield burners use a hydraulic system to prevent after-burn, ensuring precise shutdown and optimized oil burn-out behavior. High-alloyed steel nozzles handle variable oil quality, while a spillback type valve manages oil supply.
- Gas Control: Gaseous fuel is injected at high velocity into the air stream before the stainless steel diffuser, through a flange butterfly valve. The completely linkageless procedure ensures accuracy and efficiency. Optional gas control train equipment includes filters, regulators, and high-pressure shut-off valves for customizable performance.
Limpsfield Burners Summary
Limpsfield Combustion delivers burners with capacities from 1 to 100 MMBtu/hr. Their forced draft burners support gaseous and liquid fuels, featuring independent fuel and air inlet orientation for flexible applications. Engineered for efficiency, they offer hydraulic oil control to prevent after-burn, high-velocity gas injection with linkageless valves, and robust construction with service-friendly access.
Limpsfield burners meet strict U.S. low NOx standards, achieving sub-30 ppm NO emissions at 3% O₂ through flue gas recirculation and superior flame retention. UL-approved control panels optimize performance, ensuring reliability and ISO9001-certified design.
